            Multi Jet Dry Dial Water Meter

            Multi Jet Dry Dial Water Meter
            Multi Jet Dry Dial Water Meter
            Send Inquiry
            Product Code : 17
            Product Description

            Multi Jet Dry Dial Water Meter

            25mm Multi-Jet HOT Water Meter

            Salient Features

            • Sealed extra dry totaliser.
            • High flow-rates enduring capacities.
            • Maximum corrosion protection.
            • No effect by external magnetic fields.
            • Measuring mechanism can be removed without interrupting water supply.

            Metrological Performance and Dimensions.

            Size of Meter - mm
            50
            65
            80
            100
            150
            200
            250
            300
            QsQmax
            Max. Peak flow, +- 2% m3/hr
            30
            50
            80
            120
            300
            500
            800
            1200
            Q[/Qn
            Nominal flow, +-2% m3/hr
            15
            25
            40
            60
            150
            250
            400
            600
            Qt.
            Transitional flow, +-2% m3/hr
            3
            5
            8
            12
            30
            50
            80
            120
            Qmin
            Minimum flow, +- 5% m3/hr
            0.45
            0.75
            1.20
            1.80
            4.50
            7.50
            12.00
            18.00
            Overall Length mm
            200
            200
            200
            250
            300
            350
            450
            500
            O.D. of Flange mm
            165
            185
            200
            220
            285
            340
            395
            445
            Flange Thickness mm
            19
            19
            21
            22
            23
            24.5
            26
            27.5
            Dia of Bolt circle (PCD) mm
            125
            145
            160
            180
            240
            295
            350
            400
            Dia of Holes mm
            19
            19
            19
            19
            23
            23
            23
            23
            No. of Bolts
            4
            4
            4
            8
            8
            8
            12
            12
            Weight kg (Approx)
            11.4
            12.6
            14.1
            19.5
            34
            55
            75
            175
